SIM card holder microSD clamshell 1.50 high

category:microSD/TF Series
The number of clicks:
Release date:2018/06/22
Inquiry

details

Product ID:	XNT-TF-XG150H
product name:	microSD clamshell 1.50 high
specification:	Plastic: black high temperature UL94V-0; terminal: copper alloy; shell: stainless steel;
Product Note:	Micro SD flip cover L13.50W13.30H1.50
Product Category:	microSD TF SD Series

Technical parameters:
1. Rated current: 0.5mA AC/DC
2. Rated voltage: 100V AC/DC
3. Operating temperature: -25°C ~ +85°C
4. Storage temperature: -40°C ~ +85°C
5. Contact resistance :50m ohms max.
6. Insulation resistance: 1000M ohms min./500VDC
7. Durability: 10000 times
8. Product temperature resistance: 260±5°C 10S
9. RoHS Compliant
:
1. This connector is widely used in mobile phones , Tablet PCs, navigators, LCD TVs, automobiles, smart wearable devices, aeronautics, etc.;
2. Secondary product inspection processes are: IQC feed inspection -> storage -> pre-line self-test -> IPQC inspection - -> FQC final inspection -> OQC cargo inspection
3. This product production process is: pre-line inspection -> automatic machine-cutting molding material tape -> assembly of the shell -> card test -> electrical inspection - ->Flatness test-->Positiveity test-->Appearance test-->FQC test-->Package-->Storage
