Headphone Holder 3.5mm phone jack 5PIN Shen board 2.70mm DIP type

category:Headset
The number of clicks:
Release date:2018/06/22
Inquiry

details

Product ID:	XNT-R05GA-4ZL2
product name:	3.5mm phone jack 5PIN sink 2.70mm DIP type 上斜口
specification:	Plastic: Black high temperature UL94V-0; Terminal: Copper alloy
Product Note:	022 3.5mm Audio jack female, sink type
Product Category:	Headphone Stand Power DC Block Series

Technical parameters:
1. Rated current: 1.0A
2. Contact resistance: 50m ohms max.
3. Withstand voltage: 500V AC min.
4. Insulation resistance: 1000M ohms min./500VDC
5. Durability: 5000 times
6. Product resistance Temperature: 245±5°C 10S
7. RoHS Compliant
Product Description:
1. This connector is widely used in mobile phones, computers, flat panels, navigators, LCD TVs, etc.;
2. This product inspection process is: IQC feed inspection -> Storage -> before the on-line self-test -> IPQC inspection -> FQC final inspection -> OQC cargo inspection
3. This product production process is: pre-line inspection -> automatic machine plug terminal -> electrical Inspection-->pressure test-->hole inspection-->appearance inspection-->FQC inspection-->storage
